Flake Rotary slips Type W Slip W3.5-5/100 W5-7/100
Flake Rotary Slips have three segments. They can handle various O.D.drill pipes, drill collars and casings by changing inserts or insert bowls. There are two types of such slips. W3.5-5/100 and W5-7/100.The products are designed and manufactured according to API Spec 7K pecification for drilling and well servicing equipment.
| Main Technical Parameters | ||||||||
| Model | W3.5-5/100 | |||||||
| Size of Tubulars | in | 2 7/8 | 3 1/2 | 4 | 4 1/8 | 4 1/2 | 4 3/4 | 5 |
| mm | 73.025 | 88.9 | 101.6 | 104.775 | 114.3 | 120.65 | 127 | |
| Max load(kN) | 1000 | |||||||
| Main Technical Parameters | ||||||||||
| Model | W5-7/100 | |||||||||
| Size of Tubulars | in | 5 | 5 1/2 | 5 9/16 | 5 3/4 | 6 1/8 | 6 1/4 | 6 1/2 | 6 5/8 | 7 |
| mm | 127 | 139.7 | 141.3 | 146.1 | 155.6 | 158.8 | 165.1 | 168.3 | 177.8 | |
| Max load(kN) | 1000 | |||||||||
