| 注入头型号
Injector Model |
GS 60K | GS 80K | GS 100K | GS 140K | GS 750 |
| 间断提升力
Intermittent Pulling Capacity |
31000 kg | 39000 kg | 50000 kg | 68000 kg | 78500 kg |
| 69000 lbs | 86000 lbs | 110000 lbs | 150000 lbs | 174444 lbs | |
| 连续提升力
Continuous Pulling Capacity |
27000 kg | 36000 kg | 45000 kg | 63000 kg | 75000 kg |
| 60000 lbs | 80000 lbs | 100000 lbs | 140000 lbs | 166667 lbs | |
| 连续下注力
Continuous Snubbing Capacity |
13500 kg | 18000 kg | 22500 kg | 31500 kg | 31500 kg |
| 30000 lbs | 40000 lbs | 50000 lbs | 70000 lbs | 70000 lbs | |
| 最小排量下的最大速度
Maximum Speed @ Min. Displacement |
67 m/min | 66 m/min | 58 m/min | 42 m/min | 37 m/min |
| 220 ft/min | 217 ft/min | 190 ft/min | 138 ft/min | 121 ft/min | |
| 最大排量下的最大速度
Maximum Speed @ Max. Displacement |
33.5 m/min | 33 m/min | 24 m/min | 21 m/min | 18 m/min |
| 110 ft/min | 108 ft/min | 79 ft/min | 69 ft/min | 59 ft/min | |
| 最小平稳速度
Minimum Stationary Speed |
＜0.3m/min | ||||
| 适用油管规格
Applicable Tubing Size |
1.25″-2.375″ | 1.5″-2.875″ | 1.5″-2.875″ | 2″-3.5″ | 2″-3.5″ |
| 鹅颈规格
Goose neck specification |
72″/100″/120″/140″ | ||||
